START540 - NPN Silicon RF Transistor

Datasheet Summary

Description

The START540 is a member of the START family that provide the market with the state of the art of RF silicon process.

Manufacturated in the third generation of ST proprietary bipolar process, it offers the highest linearity with excellent Noise Figure for 4.5V breakdown voltage(BVceo).

📥 Download Datasheet

Datasheet preview – START540

Datasheet Details

Part number START540
Manufacturer STMicroelectronics
File Size 90.54 KB
Description NPN Silicon RF Transistor
Datasheet download datasheet START540 Datasheet
Additional preview pages of the START540 datasheet.

📁 Similar Datasheet

  • STAR1000 - STAR1000 1M Pixel Radiation Hard CMOS Image Sensor (Cypress Semiconductor)
  • STAR405F10 - Laser Diode Module (Roithner)
  • STAR405F20 - Laser Diode Module (Roithner)
  • STAR405F5 - Laser Diode Module (Roithner)
  • STAR450F10 - Laser Diode Module (Roithner)
  • STAR450F5 - Laser Diode Module (Roithner)
  • STA-42D1004 - 2 Phase Hybrid Stepping Motor (Shinano Kenshi)
  • STA-42D1005 - 2 Phase Hybrid Stepping Motor (Shinano Kenshi)
  • STA-42D1006 - 2 Phase Hybrid Stepping Motor (Shinano Kenshi)
  • STA-42D1007 - 2 Phase Hybrid Stepping Motor (Shinano Kenshi)
Other Datasheets by ST Microelectronics

Full PDF Text Transcription

Click to expand full text
www.DataSheet4U.com START540 NPN Silicon RF Transistor • LOW NOISE FIGURE: NFmin = 0.9dB @ 1.8GHz, 5mA, 2V • HIGH OUTPUT IP3 = 24dBm @ 1.8GHz, 20mA, 2V • GOOD RUGGEDNESS BVceo = 4.5V • TRANSITION FREQUENCY 45GHz • ULTRA MINIATURE SOT343 PACKAGE SOT343 (SC70) ORDER CODE START540TR BRANDING 540 DESCRIPTION The START540 is a member of the START family that provide the market with the state of the art of RF silicon process. Manufacturated in the third generation of ST proprietary bipolar process, it offers the highest linearity with excellent Noise Figure for 4.5V breakdown voltage(BVceo). It reaches performance level only achieved with GaAs products before.
