CR08AS-12A - 600V 0.8A Thyristor

Key Features

  • IT (AV) : 0.8 A.
  • VDRM : 600 V.
  • IGT: 100 μA Outline Preliminary Datasheet R07DS0489EJ0300 Rev.3.00 May 22, 2013.
  • Non-Insulated Type.
  • Planar Type.
  • Surface Mounted type.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
CR08AS Thyristor Mitsubishi Electric Semiconductor
CR08AS 0.8A Phase Control SCR Powerex Power Semiconductors
CR08AS Thyristor Kexin
CR0800SA The CR range of protectors are based on the proven technology of the T10 thyristor product Littelfuse
CR0800SB The CR range of protectors are based on the proven technology of the T10 thyristor product Littelfuse

Other Datasheets by Renesas

Part Number Description
CR08AS-12 Thyristor
CR02AM-8 Thyristor
CR03AM-16A Thyristor
CR04AM-12A Thyristor
CR05AM-16A Thyristor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
CR08AS-12A 600V - 0.8A - Thyristor Low Power Use Features • IT (AV) : 0.8 A • VDRM : 600 V • IGT: 100 μA Outline Preliminary Datasheet R07DS0489EJ0300 Rev.3.00 May 22, 2013 • Non-Insulated Type • Planar Type • Surface Mounted type RENESAS Package code: PLZZ0004CA-A (Package name: UPAK) 3 2 1 4 2, 4 3 1 1. Cathode 2. Anode 3. Gate 4. Anode Applications Solid state relay, strobe flasher, igniter, and hybrid IC Maximum Ratings Parameter Repetitive peak reverse voltage Non-repetitive peak reverse voltage DC reverse voltage Repetitive peak off-state voltage Note1 DC off-state voltage Note1 Parameter RMS on-state current Average on-state current Symbol IT(RMS) IT(AV) Symbol VRRM VRSM VR(DC) VDRM VD(DC) Ratings 1.26 0.8 Surge on-state current I2t for fusing ITSM 10 I2t 0.
