CR08AS-12 - Thyristor

Key Features

  • IT (AV) : 0.8 A.
  • VDRM : 600 V.
  • IGT : 100 A Outline.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
CR08AS Thyristor Mitsubishi Electric Semiconductor
CR08AS 0.8A Phase Control SCR Powerex Power Semiconductors
CR08AS Thyristor Kexin
CR0800SA The CR range of protectors are based on the proven technology of the T10 thyristor product Littelfuse
CR0800SB The CR range of protectors are based on the proven technology of the T10 thyristor product Littelfuse

Other Datasheets by Renesas

Part Number Description
CR08AS-12A 600V 0.8A Thyristor
CR02AM-8 Thyristor
CR03AM-16A Thyristor
CR04AM-12A Thyristor
CR05AM-16A Thyristor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
CR08AS-12 Thyristor Low Power Use Features  IT (AV) : 0.8 A  VDRM : 600 V  IGT : 100 A Outline RENESAS Package code: PLZZ0004CA-A (Package name: UPAK) 3 2 1 4 Preliminary Datasheet R07DS0133EJ0500 (Previous: REJ03G0349-0400) Rev.5.00 Sep 10, 2010  Non-Insulated Type  Glass Passivation Type  Surface Mounted type RENESAS Package code: PLZZ0004CB-A (Package name: SOT-89) KG 4 LP1 O2 E3 3 2, 4 1 1. Cathode 2. Anode 3. Gate 4.
