MOSFET - Power, DUAL COOL) N-Channel DFN8 5x6
60 V, 1.5 mW, 224 A
NVMFSC1D6N06CL
Features
• Advanced Dual−sided Cooled Packaging • Ulra Low RDS(on) • MSL1 Robust Packaging Design • AEC−Q101 Qualified
Typical Applications
• Orring FET/Load Switching • Synchronous Rectifier • DC−DC Conversion
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
Parameter
Symbol Value Unit
Drain−to−Source Voltage
VDSS
60
V
Gate−to−Source Voltage
VGS
±20
V
Continuous Drain
Steady TC = 25°C
ID
Current RqJC (Note 2) State TC = 100°C
ID
224
A
158.6 A
Power Dissipation RqJC (Note 2)
Steady TC = 25°C
PD
State
TC = 100°C
PD
166 W
83
W
Continuous Drain Current RqJA (Notes 1, 2)
Steady TA = 25°C
ID
State
TA = 100°C
ID
35
A
24.
