NTGS3136P, NVGS3136P
MOSFET – Power, Single, P-Channel, TSOP-6
-20 V, -5.8 A
Features
• Low RDS(on) in TSOP−6 Package • 1.8 V Gate Rating • Fast Switching • NV Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
Applications
• Optimized for Battery and Load Management Applications in
Portable Equipment
• High Side Load Switch • Switching Circuits for Game Consoles, Camera Phone, etc.
MAXIMUM RATINGS (TJ = 25°C unless otherwise stated)
Parameter
Symbol Value Unit
Drain−to−Source Voltage
VDSS
−20
V
Gate−to−Source Voltage
VGS
$8.0
V
Continuous Drain Current (Note 1)
Steady TA = 25°C
ID
State TA = 85°C
−5.1
−3.
