MMST5401 - PNP Small Signal Transistors

Key Features

  • Halogen free available upon request by adding suffix "-HF".
  • Power dissipation: 200mW (Tamb=25ć).
  • Collector current: -0.2A.
  • Marking : K4M.
  • Operating and Storage junction temperature range -55ć to + 150ć.
  • Lead Free Finish/RoHS Compliant ("P" Suffix designates RoHS Compliant. See ordering information).
  • Epoxy meets UL 94 V-0 flammability rating.
  • Moisure Sensitivity Level 1 Electrical Characteristics @ 25OC Unless Otherwise.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MMST5401 160V PNP SMALL SIGNAL TRANSISTOR Diodes Incorporated
MMST5401 PNP General Purpose Transistor GME
MMST5401 PNP Transistors Kexin
MMST5401 BIPOLAR TRANSISTORS Rectron
MMST5401 PNP General Purpose Transistor Multicomp

Other Datasheets by Micro Commercial Components

Part Number Description
MMST5551 NPN Small Signal Transistors
MMST2222A NPN Plastic-Encapsulate Transistors
MMST2907A PNP Small Signal Transistors
MMST3904 NPN Small Signal Transistors
MMST3906 PNP Small Signal Transistors
MMST4401 NPN Small Signal Transistors
MMSTA42 NPN Small Signal Transistors
MMS9012 PNP Silicon Transistor
MMS9012-H PNP Silicon Transistor
MMS9012-L PNP Silicon Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
MCC TM Micro Commercial Components   omponents 20736 Marilla Street Chatsworth    !"# $ %    !"# Features • Halogen free available upon request by adding suffix "-HF" • Power dissipation: 200mW (Tamb=25ć) • Collector current: -0.2A • Marking : K4M • Operating and Storage junction temperature range -55ć to + 150ć • Lead Free Finish/RoHS Compliant ("P" Suffix designates RoHS Compliant. See ordering information) • Epoxy meets UL 94 V-0 flammability rating • Moisure Sensitivity Level 1 Electrical Characteristics @ 25OC Unless Otherwise Specified Symbol Parameter Min Max Units OFF CHARACTERISTICS (2) V(BR)CEO V(BR)CBO V(BR)EBO ICEO IEBO hFE VCE(sat) VBE(sat) fT Cob NF Collector-Emitter Breakdown Voltage (IC=-1.
