KX8N60CF - N-Channel MOSFET

Key Features

  • s.
  • VDS (V) = 600V.
  • ID = 7.5 A (VGS = 10V).
  • RDS(ON) ＜ 1.2 Ω (VGS = 10V).
  • Fast switching.
  • Improved dv/dt capability D G S 15.87 ±0.20 3.30 ±0.20 TO-220F ±0.20 3.18±0.20 φ ±0.20 2.54 ±0.20 Unit: mm 0.70 ±0.20 6.68 ±0.20 12.42 ±0.20 1.47max 9.75 ±0.20 2.54typ 2.54typ 1 23 0.80 ±0.20 0.50 ±0.20 2.76 ±0.20.
  • Absolute Maximum Ratings Ta = 25℃ Parameter Drain-Source Voltage Gate-Source Voltage Continuous Drain Current Tc=25℃ Tc=100℃ Pulsed Drain Current A.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer

Other Datasheets by Kexin Semiconductor

Part Number Description
KX8N60C N-Channel MOSFET
KX8530 PFM Step-up DC/DC Converter

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
DIP Type N-Channel MOSFET KX8N60CF MOSFET ■ Features ● VDS (V) = 600V ● ID = 7.5 A (VGS = 10V) ● RDS(ON) ＜ 1.2 Ω (VGS = 10V) ● Fast switching ● Improved dv/dt capability D G S 15.87 ±0.20 3.30 ±0.20 TO-220F ±0.20 3.18±0.20 φ ±0.20 2.54 ±0.20 Unit: mm 0.70 ±0.20 6.68 ±0.20 12.42 ±0.20 1.47max 9.75 ±0.20 2.54typ 2.54typ 1 23 0.80 ±0.20 0.50 ±0.20 2.76 ±0.20 ■ Absolute Maximum Ratings Ta = 25℃ Parameter Drain-Source Voltage Gate-Source Voltage Continuous Drain Current Tc=25℃ Tc=100℃ Pulsed Drain Current Avalanche Current Power Dissipation Tc=25℃ Derate above 25℃ Single Pulsed Avalanche Energy (Note.1) Repetitive Avalanche Energy Peak Diode Recovery dv/dt (Note.2) Thermal Resistance.Junction- to-Ambient Thermal Resistance.
