BCP51 Datasheet PNP Transistors

Manufacturer: Kexin Semiconductor

📥 Download Datasheet

Overview

SMD Type PNP Transistors BCP51,BCP52,BCP53 (KCP51,KCP52,KCP53) Transistors.

Key Features

  • s.
  • For AF driver and output stages.
  • High collector current.
  • Low collector-emitter saturation voltage.
  • Complementary to BCP54,BCP55,BCP56 SOT-223 6.50±0.2 3.00±0.1 4 10b Unit:mm 7.0±0.3 3.50±0.2 1.80 (max) 0.02 ~ 0.1 1 2 3 2.30 (typ) 4.60 (typ) 0.70±0.1 0.250 Gauge Plane 1.Base 2.Collector 3.Emitter 4.Collector.
  • Absolute Maximum Ratings Ta = 25℃ Parameter Collector - Base Voltage Collector - Emitter Voltage Emitter - Base Voltage Collector Current - Continu.
