The 74LVC1G97-Q100 by nexperia is a Low-power configurable multiple function gate. Below is the official datasheet preview.

📥 Download Datasheet

74LVC1G97-Q100 Low-power configurable multiple function gate by nexperia - Datasheet Preview — Official preview page of the 74LVC1G97-Q100 Low-power configurable multiple function gate datasheet (nexperia).

Datasheet Details

Part number	74LVC1G97-Q100
Manufacturer	nexperia
File Size	221.39 KB
Description	Low-power configurable multiple function gate
Datasheet	74LVC1G97-Q100-nexperia.pdf
Additional preview pages of the 74LVC1G97-Q100 datasheet.

74LVC1G97-Q100 Product details

Description

The 74LVC1G97-Q100 is a configurable multiple function gate with Schmitt-trigger inputs.

Features

Automotive product qualification in accordance with AEC-Q100 (Grade 1).
Specified from -40 °C to +85 °C and -40 °C to +125 °C.
Wide supply voltage range from 1.65 V to 5.5 V.
5 V tolerant input/output for interfacing with 5 V logic.
High noise immunity.
Complies with JEDEC standard:.
JESD8-7 (1.65 V to 1.95 V).
JESD8-5 (2.3 V to 2.7 V).
JESD8B/JESD36 (2.7 V to 3.6 V).
±24 mA output drive (VCC = 3.0 V).
