LCP114E, LCP100E - 1W Miniature SMT DC/DC Con vert ers

Name: LCP114E
SKU: LCP114E-793274

micropowerdirect

The LCP114E by micropowerdirect is a 1W Miniature SMT DC/DC Con vert ers. Below is the official datasheet preview.

Datasheet Details

Part number	LCP114E, LCP100E
Manufacturer	micropowerdirect
File Size	307.84 KB
Description	1W Miniature SMT DC/DC Con vert ers
Datasheet	LCP100E-micropowerdirect.pdf
Note	This datasheet PDF includes multiple part numbers: LCP114E, LCP100E. Please refer to the document for exact specifications by model.
Additional preview pages of the LCP114E datasheet.

1W Output Power.
Miniature SMT Case.
DCP01 Series Replacement.
1,500 VDC Isolation.
Short Circuit Protected.
>3.5 MHour MTBF.
DIP Ver Available (ACP100E).
LOW, LOW COST!! Speciﬁcations typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Speciﬁcations subject to change without notice. Input Parameter Input Voltage Range Input Filter Conditions 5 VDC Input 12 VDC Input Min. 4.50 10.80 Typ.
