TPS2301, TPS2300 - DUAL HOT-SWAP POWER CONTROLLERS

Texas Instruments

📥 Download Datasheet

TPS2301 Datasheet Preview — This datasheet PDF includes multiple part numbers: TPS2301, TPS2300. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	TPS2301, TPS2300
Manufacturer	Texas Instruments
File Size	504.85 KB
Description	DUAL HOT-SWAP POWER CONTROLLERS
Datasheet	TPS2300-etcTI.pdf
Note	This datasheet PDF includes multiple part numbers: TPS2301, TPS2300. Please refer to the document for exact specifications by model.

TPS2301 Product details

Description

The TPS2300 and TPS2301 are dual-channel hotswap controllers that use external N-channel MOSFETs as high-side switches in power applications.

Features

1.
Dual-Channel High-Side MOSFET Drivers.
IN1: 3 V to 13 V; IN2: 3 V to 5.5 V.
Output dV/dt Control Limits Inrush Current.
Circuit-Breaker With Programmable Overcurrent Threshold and Transient Timer.
Power-Good Reporting With Transient Filter.
CMOS- and TTL-Compatible Enable Input.
Low, 5-μA Standby Supply Current (Max).
Available in 20-Pin TSSOP Package.
40°C to 85°C Ambient Temperature Range.
Electrostati.
