DS125DF111 - Multi-Protocol 2-Channel 9.8-12.5Gb/s Retimer

Product Overview

Texas Instruments

📥 Download Datasheet

DS125DF111 Multi-Protocol 2-Channel 9.8-12.5Gb/s Retimer by Texas Instruments - Datasheet Preview — Datasheet preview – DS125DF111

Datasheet Details

Part number	DS125DF111
Manufacturer	Texas Instruments
File Size	1.37 MB
Description	Multi-Protocol 2-Channel 9.8-12.5Gb/s Retimer
Datasheet	DS125DF111 Datasheet
Additional preview pages of the DS125DF111 datasheet.

Product details

Description

The DS125DF111 is a dual channel (1-lane bidirectional) retimer with integrated signal conditioning. 15.

Features

1 Pin Compatible Retimer Family.
DS110DF111 with DFE: 8.5 - 11.3 Gbps.
DS125DF111 with DFE: 9.8 - 12.5 Gbps.
Adaptive CTLE: 33 dB Max Boost at 6.25 GHz.
Self Tuning 5-Tap DFE.
Raw Equalized and Retimed Data Loopback.
Adjustable Transmit VOD: 600 to 1300 mVp-p.
Settable Tx De-Emphasis Driver 0 to.
12dB.
Low Power Consumption: 220 mW/Channel.
Locks to Half/Quarter/Eighth Data Rates for Legacy Support.
