CDCM1802 - Clock Buffer

Product Overview

Texas Instruments

Datasheet Details

Part number	CDCM1802
Manufacturer	Texas Instruments
File Size	1.65 MB
Description	Clock Buffer
Datasheet	CDCM1802 Datasheet
Additional preview pages of the CDCM1802 datasheet.

Product details

Description

The CDCM1802 clock driver distributes one pair of differential clock input to one LVPECL differential clock output pair, Y0 and Y0, and one single-ended LVCMOS output, Y1.

Features

1 Distributes One Differential Clock Input to One LVPECL Differential Clock Output and One LVCMOS Single-Ended Output.
Programmable Output Divider for Both LVPECL and LVCMOS Outputs.
1.6-ns Output Skew Between LVCMOS and LVPECL Transitions Minimizing Noise.
3.3-V Power Supply (2.5-V Functional).
Signaling Rate Up to 800-MHz LVPECL and 200-MHz LVCMOS.
Differential Input Stage for Wide Common-Mode Range Also Provides VBB Bias Voltage Output for.
