VFT10200C - Trench MOS Barrier Schottky Rectifier

Vishay

Datasheet Details

Part number	VFT10200C
Manufacturer	Vishay
File Size	202.93 KB
Description	Trench MOS Barrier Schottky Rectifier
Datasheet	VFT10200C_Vishay.pdf

ITO-220AB.
Trench MOS Schottky technology.
Low forward voltage drop, low power losses.
High efficiency operation.
Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C (for TO-263AB package) 2 VT10200C PIN 1 PIN 3 PIN 2 CASE 3 1 VFT10200C PIN 1 PIN 3 PIN 2 2 3.
Solder dip 275 °C max. 10 s, per JESD 22-B106 (for TO-220AB, ITO-220AB and TO-262AA package).
Compliant to RoHS directive 2002/95/EC and in accordance to WEEE 2002/96/EC 1.
