SMF8V5A, SMF5V0A - Surface Mount ESD Protection Diodes

Vishay

Datasheet Details

Part number	SMF8V5A, SMF5V0A
Manufacturer	Vishay ↗
File Size	141.05 KB
Description	Surface Mount ESD Protection Diodes
Datasheet	SMF5V0A-Vishay.pdf
Note	This datasheet PDF includes multiple part numbers: SMF8V5A, SMF5V0A. Please refer to the document for exact specifications by model.

200 W peak pulse power capability with a 10/1000 μs waveform, repetition rate (duty cycle): 0.01 % Available.
Low profile package.
Wave and reflow solderable.
ESD immunity acc. IEC 61000-4-2 ± 30 kV contact discharge ± 30 kV air discharge.
ESD capability according to AEC-Q101: human body model: class H3B: > 8 kV.
Low incremental surge resistance, excellent clamping capability.
“Low Noise” technology - very fast response time.
