SMF12A Features
* 200 W peak pulse power capability with a 10/1000 μs waveform, repetition rate (duty cycle): 0.01 % Available
* Low profile package
* Wave and reflow solderable
* ESD immunity acc. IEC 61000-4-2 ± 30 kV contact discharge ± 30 kV air discharge
* ESD capa
Datasheet Details
SMF12A, SMF5V0A
141.05 KB
Surface mount esd protection diodes.
This datasheet PDF includes multiple part numbers: SMF12A, SMF5V0A.
Please refer to the document for exact specifications by model.
