GP20J, GP20A Glass Passivated Junction Rectifier

Vishay

Description

Not for New Design - End of Life - Last Available Purchase Date is 31-May-2011 GP20A thru GP20J Vishay General Semiconductor Glass Passivated Junction.

📥 Download Datasheet

GP20J Datasheet Preview — This datasheet PDF includes multiple part numbers: GP20J, GP20A. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: GP20J, GP20A
Manufacturer: Vishay ↗
File Size: 75.40 KB
Datasheet: GP20A-Vishay.pdf
Description: Glass Passivated Junction Rectifier
Note: This datasheet PDF includes multiple part numbers: GP20J, GP20A.
Please refer to the document for exact specifications by model.

Applications

* For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for both consumer and automotive applications. MECHANICAL DATA Case: GP20, molded epoxy over glass body Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS compliant, commerc
