VS40280AT-VB
VS40280AT-VB Datasheet N-Channel 40 V (D-S) MOSFET
PRODUCT SUMMARY
VDS (V)
RDS(on) (Ω)
0.0010 at VGS = 10 V 40
0.0012 at VGS = 4.5 V
ID (A)a, c 280 250
Qg (Typ.) 240 nC
TO-220AB
FEATURES • Trench Power MOSFET • 100 % Rg and UIS Tested
APPLICATIONS • Synchronous Rectification • Power Supplies
D
www.VBsemi.com
RoHS
COMPLIANT
G
GDS Top View
S N-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted
Parameter
Symbol
Drain-Source Voltage
VDS
Gate-Source Voltage
VGS
TC = 25 °C
Continuous Drain Current (TJ = 175 °C)
TC = 70 °C TA = 25 °C
ID
TA = 70 °C
Pulsed Drain Current
IDM
Avalanche Current Pulse Single Pulse Avalanche Energy
L = 0.
VS40280AT Datasheet
