TC74HC109AF, TC74HC109 - Dual J-K Flip-Flop

Toshiba

📥 Download Datasheet

TC74HC109AF Datasheet Preview — This datasheet PDF includes multiple part numbers: TC74HC109AF, TC74HC109. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	TC74HC109AF, TC74HC109
Manufacturer	Toshiba
File Size	229.40 KB
Description	Dual J-K Flip-Flop
Datasheet	TC74HC109_Toshiba.pdf
Note	This datasheet PDF includes multiple part numbers: TC74HC109AF, TC74HC109. Please refer to the document for exact specifications by model.

TC74HC109AF Product details

Features

High speed: fmax = 63 MHz (typ. ) at VCC = 5 V.
Low power dissipation: ICC = 2 μA (max) at Ta = 25°C.
High noise immunity: VNIH = VNIL = 28% VCC (min).
Output drive capability: 10 LSTTL loads.
Symmetrical output impedance: |IOH| = IOL = 4 mA (min).
Balanced p.
