LV23000 - Single-Chip Tuner IC for Radio/Cassette Players

Sanyo Semicon Device

📥 Download Datasheet

LV23000 Datasheet Preview — Preview of LV23000 PDF

Datasheet Details

Part number	LV23000
Manufacturer	Sanyo Semicon Device
File Size	144.85 KB
Description	Single-Chip Tuner IC for Radio/Cassette Players
Datasheet	LV23000_SanyoSemiconDevice.pdf

LV23000 Product details

Description

of the DI Control Data No.Control block/data Description Specifies the divisor used by the programmable dividers. 1 0 LSB P0 P0 P4 Divisor setting (N) 272 to 65535 272 to 65535 4 to 4095 Actual divisor The actual setting times 2 The actual setting The actual setting Related data Note: When P4 is the LSB, bits P0 to P3 are ignored.

Features

Tuner circuit includes built-in PLL for easy end product design.
Supports FCC standards.
Built-in adjustment-free multiplex VCO.
AM low-cut control.
Provides the transistor required to implement an active low-pass filter. 15.3 2.25 2.5max 0.65 1 18 0.25 0.4 0.8 0.85 SANYO: MFP36SD (375 mil).
CCB is a trademark of SANYO.
