Description
Pin No 1 2 3 4 Symbol OSCI OSCO VDD3 PDA I/O I O
O Description These input / output pins generate the reference frequency.
If Fr < Fn (Fr is leading), t
Features
- Maximum operating frequency: 150MHz @ 500mVP-P, VDD1 = 0.95V 180MHz @ 500mVP-P, VDD1 = 1.0V
(Magnification = 1 : 4).
- On-chip reference oscillator supports external crystal which oscillates up to 18MHz Superior supply current: (VDD1 = VDD2 = 1.0V, VDD3 = 3.0V).
- FFIN = 90MHz, IDD1 = 0.6mA (Typ. ).
- FFIN = 150MHz, IDD1 = 0.9mA (Typ. ).
- FFIN = 180MHz, IDD3 = 1.1mA (TyP. ).
- Operating voltage: VDD1 = 0.95 ~.
