Description
Input Clock Input Clock for Output Data Output Echo Clock DLL Disable when low Address Inputs Data Inputs 1 NOTE
Q0-35 W R BW0, BW1,BW2, BW3 VREF ZQ VDD VDDQ VSS TMS TDI TCK TDO NC
Data Outputs Write Control Pin, active when low Read Control Pin, active when low Block Write Control Pin, active when low Input Reference Voltage Output Driver Impedance Control Input Power Supply (1.8 V) Output Power Supply (1.5V or 1.8V) Ground JTAG Test Mode Select JTAG Test Data Input JTAG Test Clock JTAG Test
Features
- 1.8V+0.1V/-0.1V Power Supply.
- DLL circuitry for wide output data valid window and future frequency scaling.
- I/O Supply Voltage 1.5V+0.1V/-0.1V for 1.5V I/O, 1.8V+0.1V/ -0.1V for 1.8V I/O.
- Separate independent read and write data ports with concurrent read and write operation.
- HSTL I/O.
- Full data coherency, providing most current data.
- Synchronous pipeline read with self timed early write.
- Registered address, control an.
