Description
The K6R1008C1A is a 1,048,576-bit high-speed Static Random Access Memory organized as 131,072 words by 8 bits..
Features
- Fast Access Time 12, 15, 20ns(Max. ).
- Low Power Dissipation Standby (TTL) : 25mA(Max. ) (CMOS) : 8mA(Max. ) Operating K6R1008C1A-12 : 170mA(Max. ) K6R1008C1A-15 : 165mA(Max. ) K6R1008C1A-20 : 160mA(Max. ).
- Single 5.0V±10% Power Supply.
- TTL Compatible Inputs and Outputs.
- I/O Compatible with 3.3V Device.
- Fully Static Operation - No Clock or Refresh required.
- Three State Outputs.
- Center Power/Ground Pin Configuration.
- Stand.
