STM8AH61AA, STM8AH51xx - Automotive 8-bit MCU

STMicroelectronics

📥 Download Datasheet

STM8AH61AA Datasheet Preview — This datasheet PDF includes multiple part numbers: STM8AH61AA, STM8AH51xx. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	STM8AH61AA, STM8AH51xx
Manufacturer	STMicroelectronics ↗
File Size	773.43 KB
Description	Automotive 8-bit MCU
Datasheet	STM8AH51xx-STMicroelectronics.pdf
Note	This datasheet PDF includes multiple part numbers: STM8AH61AA, STM8AH51xx. Please refer to the document for exact specifications by model.

STM8AH61AA Product details

Description

. . 11 Product overview . .

Features

Core.
Max fCPU: 24 MHz.
Advanced STM8A core with Harvard architecture and 3-stage pipeline.
Average 1.6 cycles/instruction resulting in 10 MIPS at 16 MHz fCPU for industry standard benchmark LQFP48 7x7 LQFP80 14x14 LQFP64 10x10 LQFP32 7x7 Memories.
Communication interfaces.
Program memory: 48 to 128 Kbytes Flash; data retention 20 years at 55 °C after 1 kcycle.
Data memory: 1.5 to 2 Kbytes true data EEPROM; endurance 300 kcycles.
RAM: 3 to 6 Kbytes.
