STPS20L120C - Low drop power Schottky rectifier

Description

Dual center tap Schottky rectifier suited for high frequency switch mode power supplies.

Packaged in TO-220AB and TO-220FPAB, this device provides the adaptor designers with an optimized price-performance ratio.

Table 1.

Features

  • High junction temperature capability Avalanche capability specified Low forward voltage drop current A2 A1 K High frequency operation Insulated package.
  • TO-220FPAB Insulating voltage = 1500 V rms Typical package capacitance 12 pF K.
