www.DataSheet4U.com LUM-512HML350 LED displays 16×32 dot matrix unit LUM-512HML350 The LUM-512HML350 is a 16×32 dot matrix display which can be used in a wide range of applications, including alphabet, numeric, symbol and graphical displays.

A large display can be easily created by arranging a number of these dot matrix displays in an array, and they can be applied to a variety of display purposes.

A custom LSI controller has display data memory for two screens, and data for each screen can be

LUM-512HML350 Features

* 1) 16×32 dot matrix. Shape of emitting section : "2.1×2.3 2) Dimensions : 96mm×192mm 3) Clear display. 4) Three-color display is possible (red, green, and orange). 5) 1 / 16 duty dynamic scan method. 6) Ultra-thin shape of 9.1mm, light weight of 100g and wide directional characteristics of 100 degre
