IDT723666, IDT723656 - CMOS TRIPLE BUS SyncFIFO

Name: IDT723666
SKU: IDT723666-1492996

Renesas

📥 Download Datasheet

IDT723666 Datasheet Preview — This datasheet PDF includes multiple part numbers: IDT723666, IDT723656. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	IDT723666, IDT723656
Manufacturer	Renesas
File Size	762.17 KB
Description	CMOS TRIPLE BUS SyncFIFO
Datasheet	IDT723656-Renesas.pdf
Note	This datasheet PDF includes multiple part numbers: IDT723666, IDT723656. Please refer to the document for exact specifications by model.

IDT723666 Product details

Description

The IDT723656/723666/723676 is a monolithic, high-speed, low-power, CMOS Triple Bus synchronous (clocked) FIFO memory which supports clock frequencies up to 83 MHz and has read access times as fast as 8ns.

Features

Serial or parallel programming of partial flags.
Memory storage capacity: IDT723656.
2,048 x 36 x 2.
Big- or Little-Endian format for word and byte bus sizes.
Loopback mode on Port A IDT723666.
4,096 x 36 x 2.
Retransmit Capability IDT723676.
8,192 x 36 x 2.
Master Reset clears data and configures FIFO, Partial Reset.
Clock frequencies up to 83 MHz (8ns access time).
Two independent FIFOs.
