DB101S - SILICON BRIDGE RECTIFIER

Product Overview

Rectron

Datasheet Details

Part number	DB101S
Manufacturer	Rectron
File Size	642.96 KB
Description	SILICON BRIDGE RECTIFIER
Datasheet	DB101S Datasheet
Additional preview pages of the DB101S datasheet.

Product details

Description

- + Part No.DB10X Year code (Y: Last digit of year & A:2010, B:2011) ~V Y W W ~ Week code: (WW:01~52) Rectron Logo Voltage-code 1-------50V 5-------600V 2-------100V 6-------800V 3-------200V 7-----1000V 4-------400V PACKAGING OF DIODE AND BRIDGE RECTIFIERS REEL PACK PACKAGE PACKING EA PER CODE REEL EA PER INNER BOX COMPONENT SPACE TAPE SPACE (mm) (mm) REEL DIA (mm) CARTON SIZE EA PER (mm) CARTON GROSS WEIGHT(Kg) DB-S -T/W 1,000 1,000 9.5 52 330 360

Features

Good for automation insertion.
Surge overload rating - 30 amperes peak.
Ideal for printed circuit board.
Reliable low cost construction utilizing molded.
Glass passivated device.
Polarity symbols molded on body.
Mounting position: Any.
