PL8325B - 2.4A Monolithic Step-Down Switching Regulator

📥 Download Datasheet

PL8325B Datasheet Preview — Preview of PL8325B PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	PL8325B
Manufacturer	Powlicon
File Size	1.63 MB
Description	2.4A Monolithic Step-Down Switching Regulator
Datasheet	PL8325B-Powlicon.pdf

PL8325B Product details

Description

The PL8325B is a monolithic 36V, 2.4A step-down switching regulator with CC/CV control loop.

Features

2.4A continuous output current capability.
6.5V to 36V wide operating input range with 33V input Over Voltage Protection.
Integrated 36V, 108mΩ high side and 36V, 102mΩ low side power MOSFET switches.
Up to 95% efficiency.
Internally fixed 3A constant current control.
Programmable Soft-Start limits the inrush current at turn-on.
Stable with Low ESR Ceramic Output Capacitors.
Fixed 100KHz Switching Frequency.
Input Under-Voltage Lockout. Output Over-V.
