MOSFET - P-Channel, D2PAK
-60 V, -27.5 A
NTB25P06, NVB25P06
Designed for low voltage, high speed switching applications and to withstand high energy in the avalanche and commutation modes.
Features
AEC Q101 Qualified − NVB25P06 These Devices are Pb−Free and are RoHS Compliant
Typical Applications
PWM Motor Controls Power Supplies Converters Bridge Circuits
MAXIMUM RATINGS (TJ = 25C unless otherwise noted)
Rating
Symbol Value Unit
Drain−to−Source Voltage
Gate−to−Source Voltage − Continuous − Non−Repetitive (tpv10 ms)
Drain Current − Continuous @ TA = 25C − Single Pulse (tpv10 ms)
Total Power Dissipation @ TA = 25C
Operating and Storage Temperature Range
VDSS
−60
V
VGS
"15
V
VGSM "20 Vpk
ID
27.
