MC100EL13 - Dual 1:3 Fanout Buffer

Product Overview

ON Semiconductor

📥 Download Datasheet

MC100EL13 Dual 1:3 Fanout Buffer by ON Semiconductor - Datasheet Preview — Datasheet preview – MC100EL13

Datasheet Details

Part number	MC100EL13
Manufacturer	ON Semiconductor
File Size	131.67 KB
Description	Dual 1:3 Fanout Buffer
Datasheet	MC100EL13 Datasheet
Additional preview pages of the MC100EL13 datasheet.

Product details

Features

500 ps Typical Propagation Delays.
50 ps Output-Output Skews.
The 100 Series Contains Temperature Compensation.
PECL Mode Operating Range:.
VCC = 4.2 V to 5.7 V with VEE = 0 V.
NECL Mode Operating Range:.
VCC = 0 V with VEE =.
4.2 V to.
5.7 V.
Internal Input Pulldown Resistors.
Q Output will Default LOW with Inputs Open or at VEE.
Internal Input Pulldown Resistors on All Inputs, Pullup Resi.
