DS90CR581 - LVDS Transmitter 24-Bit Color Flat Panel Display Link

Product Overview

National Semiconductor

Part number	DS90CR581
Manufacturer	National Semiconductor
File Size	203.85 KB
Description	LVDS Transmitter 24-Bit Color Flat Panel Display Link
Datasheet	DS90CR581 Datasheet
Additional preview pages of the DS90CR581 datasheet.

The DS90CR581 transmitter converts 28 bits of CMOS/TTL data into four LVDS (Low Voltage Differential Signaling) data streams.

n n n n n n n n n Up to 140 Megabyte/sec Bandwidth Narrow bus reduces cable size and cost 290 mV swing LVDS devices for low EMI Low power CMOS design Power down mode PLL requires no external components Low profile 56-lead TSSOP package Rising edge data strobe Compatible with TIA/EIA-644 LVDS standard Block Diagrams DS90CR581 DS012487-29 Order Number DS90CR581MTD See NS Package Number MTD56.
