DS75110A - Dual Line Drivers

National Semiconductor

Datasheet Details

Part number	DS75110A
Manufacturer	National Semiconductor
File Size	306.96 KB
Description	Dual Line Drivers
Datasheet	DS75110A_NationalSemiconductor.pdf

The DS75110A is a dual line driver with independent channels, common supply and ground terminals featuring constant current outputs.

n Improved stability over supply voltage and temperature ranges n Constant current, high impedance outputs n High speed: 15 ns max propagation delay n Standard supply voltages n Inhibitor available for driver selection n High common mode output voltage range (.
3.0V to 10V) n TTL input compatibility Connection Diagram 14.
Lead Dual-In-Line Package and SO-14 Package Function Table Inputs Logic 1 X X L X H H = High L = Low X = Don’t Care Outputs Inhibitor A/B L X H H H INH X L H H.
