DS75107 - Dual Line Receiver

National Semiconductor

Datasheet Details

Part number	DS75107
Manufacturer	National Semiconductor
File Size	227.26 KB
Description	Dual Line Receiver
Datasheet	DS75107_NationalSemiconductor.pdf

The product described herein is a TTL compatible dual high speed circuit intended for sensing in a broad range of system applications.

Diode protected input stage for power “OFF” condition 17 ns typ high speed TTL compatible ± 10 mV or ± 25 mV input sensitivity ± 3V input common-mode range High input impedance with normal VCC, or VCC = 0V Strobes for channel selection Dual circuits Sensitivity gntd. over full common-mode range Logic input clamp diodes.
meets both “A” and “B” version specifications n ± 5V standard supply voltages n n n n n n n n n n Connection Diagram Dual-In-Line Package DS009446-1 Top View Order Nu.
