DS25MB200 - Dual 2.5 Gbps 2:1/1:2 CML Mux/Buffer

National Semiconductor

Datasheet Details

Part number	DS25MB200
Manufacturer	National Semiconductor
File Size	348.65 KB
Description	Dual 2.5 Gbps 2:1/1:2 CML Mux/Buffer
Datasheet	DS25MB200_NationalSemiconductor.pdf

The DS25MB200 is a dual signal conditioning 2:1 multiplexer and 1:2 fan-out buffer designed for use in backplane redundancy applications.

include input equalization and programmable output pre-emphasis that enable data communication in FR4 backplanes up to 2.5 Gbps. Each input stage has a fixed equalizer to reduce ISI distortion from board traces. All output drivers have 4 selectable steps www. DataSheet4U. com of pre-emphasis to compensate for transmission losses from long FR4 backplanes and reduce deterministic jitter. The preemphasis levels can be independently controlled for the lineside and switch-side drivers. The internal loo.
