DM74LS368A - Hex TRI-STATE Inverting Buffers

National Semiconductor

📥 Download Datasheet

DM74LS368A Datasheet Preview — Preview of DM74LS368A PDF

Datasheet Details

Part number	DM74LS368A
Manufacturer	National Semiconductor
File Size	128.59 KB
Description	Hex TRI-STATE Inverting Buffers
Datasheet	DM74LS368A-NationalSemiconductor.pdf

DM74LS368A Product details

Description

This device contains six independent gates each of which performs an inverting buffer function The outputs have the TRI-STATE feature When enabled the outputs exhibit the low impedance characteristics of a standard LS output with additional drive capability to permit the driving of bus lines without external resistors When disabled both the output transistors are turned off presenting a high-impedance state to the bus line Thus the output will act neither as a significant load nor as a driver To

Features

Y Alternate Military Aerospace device (54LS368) is available Contact a National Semiconductor Sales Office Distributor for specifications Connection Diagram Dual-In-Line Package TL F 6430.
1 Order Number 54LS368ADMQB 54LS368AFMQB 54LS368ALMQB DM54LS368AJ DM54LS368AW DM74LS368AM or DM74LS368AN See NS Package Number E20A J16A M16A N16E or W16A Function Table YeA Inputs Output AG Y LL HL XH H L Hi-Z H e High Logic Level L e Low Logic Level X e Either Low or High Logic Level Hi-.
