ISP1106DH - Advanced Universal Serial Bus transceivers

Datasheet Details

Part number	ISP1106DH
Manufacturer	NXP
File Size	588.89 KB
Description	Advanced Universal Serial Bus transceivers
Datasheet	ISP1106DH_PhilipsSemiconductors.pdf

The ISP1105/1106/1107 range of Universal Serial Bus (USB) transceivers are fully compliant with the Universal Serial Bus Speciﬁcation Rev.

s s s s s s s s s s s s Complies with Universal Serial Bus Speciﬁcation Rev. 1.1 Integrated bypassable 5 V to 3.3 V voltage regulator for powering via USB VBUS VBUS disconnection indication through VP and VM Used as a USB device transceiver or a USB host transceiver Supports full-speed (12 Mbit/s) and low-speed (1.5 Mbit/s) serial data rates Stable RCV output during SE0 condition Two single-ended receivers with hysteresis Low-power operation Supports an I/O voltage range from 1.65 V to 3.6 V 4 k.
