UM10562 - LPC408x/407x User manual

Name: UM10562
SKU: UM10562-729120

NXP Semiconductors

📥 Download Datasheet

UM10562 Datasheet Preview — Preview of UM10562 PDF

Datasheet Details

Part number	UM10562
Manufacturer	NXP Semiconductors
File Size	6.87 MB
Description	LPC408x/407x User manual
Datasheet	UM10562_NXPSemiconductors.pdf

UM10562 Product details

Description

Inital LPC408x/407x User manual version. 13 September 2012 2 of 942 datasheet pdf - http://www.DataSheet4U.net/ UM10562 Chapter 1: Introductory information Rev.1

Features

Refer to Section 1.4 for details of features for specific part numbers.
Functional replacement for LPC23xx and 24xx family devices.
ARM Cortex-M4 processor, running at frequencies of up to 120 MHz. The Cortex-M4 executes the Thumb®-2 instruction set for optimal performance and code size, including hardware division, single cycle multiply, and bit-field manipulation. A Memory Protection Unit (MPU) supporting eight regions is included.
Cortex-M4 built-in Nested Vect.
