LX1684 - Voltage-Mode PWM Controller

Microsemi Corporation

Datasheet Details

Part number	LX1684
Manufacturer	Microsemi Corporation
File Size	294.40 KB
Description	Voltage-Mode PWM Controller
Datasheet	LX1684_MicrosemiCorporation.pdf

KEY

W W W. Microsemi . COM The LX1684 is a monolithic, voltagemode pulse-width modulator controller. It is designed to implement a flexible, low cost buck (step-down) regulator supply with a minimal of external components. The LX1684 has a synchronous driver for higher efficiency and is optimized to provide 12V to 3.3V or 12V to 2.5V regulation. It also can be used to convert 5V or 3.3V to voltages as low as 1.25V. Switching frequency is fixed at 175kHz for optimal cost and space. Short-circuit cu.
