MXD8668 SP6T Switch

MXD8668 Description

MXD8668 SP6T Switch with MIPI for LTE Diversity APPROVED This document contains information that is confidential and proprietary to Maxscend Microele.
The MXD8668 is a low loss, high isolation SP6T switch for antenna diversity receiving.

MXD8668 Features

* Excellent insertion loss - 0.50 dB Insertion Loss at 2.7GHz
* P0.1dB @ 27dBm
* Multi-Band operation 700MHz to 3000MHz
* RFFE serial control interface
* Compact 2mm x 2mm in QFN-14 package
* No DC blocking capacitors required (unless external DC is applied to the RF ports)

MXD8668 Applications

* 2G/3G/4G antenna diversity
* Cellular modems and USB Devices Functional Block Diagram and Pin Function 4 3 2 1 RF1 RF2 RF3 Grou nd RF4 ANT Paddle RF5 RF6 VIO SCLK VDD SDATA Figure 1. Functional Block Diagram and Pinout (Top View) Maxscend Microelectronics Company Limited. All
