MAX509 - Quad / Serial 8-Bit DACs

Product Overview

Maxim

Part number	MAX509
Manufacturer	Maxim
File Size	348.32 KB
Description	Quad / Serial 8-Bit DACs
Datasheet	MAX509 Datasheet
Additional preview pages of the MAX509 datasheet.

The MAX509/MAX510 are quad, serial-input, 8-bit voltage-output digital-to-analog converters (DACs).

o o o o o Single +5V or Dual ±5V Supply Operation Output Buffer Amplifiers Swing Rail-to-Rail Reference Input Range Includes Both Supply Rails Calibrated Offset, Gain, and Linearity (1LSB TUE) 10MHz Serial Interface, Compatible with SPI, QSPI (CPOL = CPHA = 0) and Microwire o Double-Buffered Registers for Synchronous Updating o Serial Data Output for Daisy-Chaining o Power-On Reset Clears Serial Interface and Sets All Registers to Zero MAX509/MAX510 ______________Ordering Information PART MAX5.
