MAX5981B - Powered Device Interface Controllers

Product Overview

Maxim Integrated

Datasheet Details

Part number	MAX5981B
Manufacturer	Maxim Integrated
File Size	1.30 MB
Description	Powered Device Interface Controllers
Datasheet	MAX5981B Datasheet
Note	This datasheet PDF includes multiple part numbers: MAX5981B, MAX5981A. Please refer to the document for exact specifications by model.
Additional preview pages of the MAX5981B datasheet.

Product details

Description

The MAX5981 provides a complete interface for a powered device (PD) to comply with the IEEE® 802.3af/at standard in a power-over-ethernet (PoE) system.

Features

an input UVLO with wide hysteresis and long deglitch time to compensate for twisted-pair cable resistive drop and to assure glitch-free transition during power-on/-off conditions. The MAX5981 can withstand up to 100V at the input. The MAX5981 supports a 2-Event classification method as specified in the IEEE 802.3at standard and provides a signal to indicate when probed by a Type 2 power sourcing equipment (PSE). The device detects the presence of a wall adapter power source connection and allo.
