MAX9420 - (MAX9420 - MAX9423) Quad Differential LVECL-to-LVPECL Translators

Maxim Integrated Products

The MAX9420 by Maxim Integrated Products is a (MAX9420 - MAX9423) Quad Differential LVECL-to-LVPECL Translators. Below is the official datasheet preview.

📥 Download Datasheet

MAX9420 (MAX9420 - MAX9423) Quad Differential LVECL-to-LVPECL Translators by Maxim Integrated Products - Datasheet Preview — Official preview page of the **MAX9420** (MAX9420 - MAX9423) Quad Differential LVECL-to-LVPECL Translators datasheet (Maxim Integrated Products).

Datasheet Details

Part number	MAX9420
Manufacturer	Maxim Integrated Products
File Size	374.54 KB
Description	(MAX9420 - MAX9423) Quad Differential LVECL-to-LVPECL Translators
Datasheet	MAX9420_MaximIntegratedProducts.pdf
Additional preview pages of the MAX9420 datasheet.

MAX9420 Product details

Description

The MAX9420 MAX9423 are extremely fast, low-skew quad LVECL-to-LVPECL translators designed for highspeed signal and clock driver applications.

Features

o >500mV Differential Output at 3.0GHz Clock o 336ps (typ) Propagation Delay in Asynchronous Mode o 17ps (typ) Channel-to-Channel Skew o Integrated 50Ω Outputs (MAX9421/MAX9423) o Integrated 100Ω Inputs (MAX9422/MAX9423) o Synchronous/Asynchronous Operation MAX9420.
MAX9423 Ordering Information PART MAX9420EHJ MAX9421EHJ MAX9422EHJ MAX9423EHJ TEMP RANGE.
