MSK158 - (MSK158 / MSK159) Ultra High Voltage Operational Amplifier

MSK

The MSK158 by MSK is a (MSK158 / MSK159) Ultra High Voltage Operational Amplifier. Below is the official datasheet preview.

📥 Download Datasheet

MSK158 (MSK158 / MSK159) Ultra High Voltage Operational Amplifier by MSK - Datasheet Preview — Official preview page of the **MSK158** (MSK158 / MSK159) Ultra High Voltage Operational Amplifier datasheet (MSK).

Datasheet Details

Part number	MSK158
Manufacturer	MSK
File Size	364.66 KB
Description	(MSK158 / MSK159) Ultra High Voltage Operational Amplifier
Datasheet	MSK158_MSK.pdf
Additional preview pages of the MSK158 datasheet.

MSK158 Product details

Description

ULTRA om HIGH VOLTAGE AMPLIFIER 158/159 (315) 701-6751 MIL-PRF-38534 QUALIFIED MSK158 The MSK 158 is an ultra high voltage monolithic MOSFET operational amplifier ideally suited for electrostatic transducer and electrostatic deflection applications.With a total supply voltage rating of 350 volts and 60mA of available output current, the MSK 158 is also an excellent low cost choice for high voltage piezo drive circuits.The MOSFET output frees the MSK 158 from secondary breakdown limitatio

Features

S Monolithic MOS Technology a t Low Cost a High Voltage Operation - 350V . D Current - 2mA Max. Low Quiescent High w Output Current - 60mA Min. w No Secondary Breakdown High Speed - 40V/µS Typ. w.
