LP171WU1-A4 - Liquid Crystal Display

LP171WU1-A4 Datasheet Preview — Preview of LP171WU1-A4 PDF

Datasheet Details

Part number	LP171WU1-A4
Manufacturer	LG
File Size	512.96 KB
Description	Liquid Crystal Display
Datasheet	LP171WU1-A4_LG.pdf

LP171WU1-A4 Product details

Description

ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ELECTRICAL CHARACTREISTICS INTERFACE CONNECTIONS SIGNAL TIMING SPECIFICATIONS SIGNAL TIMING WAVEFORMS www.DataSheet.net/ ITEM Page 1 2 3 4 5 6 7 9 9 10 11 12 16 20 COLOR INPUT DATA REFERNECE POWER SEQUENCE OPTICAL SFECIFICATIONS MECHANICAL CHARACTERISTICS RELIABLITY INTERNATIONAL STANDARDS SAFETY EMC PACKING DESIGNATION OF LOT MARK PACKING FORM PRECAUTIONS APPENDIX.Enhanced Extended Display Identification Data APPENDIX.Inspection Criteria

Features

Active Screen Size Outline Dimension Pixel Pitch Pixel Format Color Depth Luminance, White Power Consumption Weight Display Operating Mode Surface Treatment 17.1 inches diagonal 382.7 (H) × 245.0 (V) × 6.6(D, max) mm 0.191 mm × 0. 191 mm 1920 horiz. by 1200 vert. Pixels RGB strip arrangement 6-bit, 262,144 colors 190 cd/m2(Typ. ) , 5 point Total 6.81 Watt(Typ. ) @ LCM circuit 2.01 Watt(Typ. ), B/L input 4.8 Watt(Typ. ) 705 g (Max. ) Transmissive mode, normally white Hard coating(3H) Anti-glare treatm.
