LP150X04 - Liquid Crystal Display

LP150X04 Datasheet Preview — Preview of LP150X04 PDF

Datasheet Details

Part number	LP150X04
Manufacturer	LG
File Size	676.01 KB
Description	Liquid Crystal Display
Datasheet	LP150X04_LG.pdf

LP150X04 Product details

Description

ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ITEM Page 1 2 3 4 5 ELECTRICAL CHARACTREISTICS INTERFACE CONNECTIONS SIGNAL TIMING SPECIFICATIONS SIGNAL TIMING WAVEFORMS COLOR INPUT DATA REFERNECE POWER SEQUENCE OPTICAL SPECIFICATIONS MECHANICAL CHARACTERISTICS RELIABILITY INTERNATIONAL STANDARDS SAFETY EMC PACKING DESIGNATION OF LOT MARK PAKING FORM PRECAUTIONS 6 8 10 11 12 13 14 18 22 23 23 24 24 25 Ver.1.0 APR.4, 2002 3 / 28 LP150X04 Liquid Crystal Display Product Specificatio

Features

Active screen size Outline Dimension Pixel Pitch Pixel format Color depth Luminance, white Power Consumption Weight Display operating mode Surface treatments 15.0 inches(38.1cm) diagonal 315.8(H) x 240.5(V) x 6.5(D) mm(Typ. ) 0.297 mm x 0.297mm 1024 horiz. By 768 vert. Pixels RGB stripes arrangement 6-bit, 262,144 colors 200 cd/m2(Typ. ) 4.76Watt (typ) 590g(Typ. ) Transmissible mode, normally white Hard coating(3H) Anti-glare treatment of the front polarizer Ver. 1.0 APR. 4, 2002 5 / 28 LP150X0.
