iT4016 - Clock phase delay

Name: iT4016
SKU: iT4016-620128

📥 Download Datasheet

iT4016 Datasheet Preview — Preview of iT4016 PDF

Datasheet Details

Part number	iT4016
Manufacturer	Iterra
File Size	270.94 KB
Description	Clock phase delay
Datasheet	iT4016_Iterra.pdf

iT4016 Product details

Description

The iT4016 is a clock phase delay with buffered output that provides a voltage-variable phase shift that allows the user to align data and clock signals with high precision.

Features

Wideband signal handling: 9 GHz to 12.5 GHz 360 deg. minimum phase shift range Output amplitude: 1.7 Vpp typical limited output AC coupled input and output Input: 0.2 Vpp to 1.4 Vpp Temperature-stable amplitude and phase response Performance and Electrical Characteristics (9 to 12.5 GHz) Parameter Output level (Vpp) Phase adjustment range Insertion delay variation with case temperature ( 0°C - 85° C) Insertion delay variation with input level (Any 3-dB change in input level, 0.2 to 1.4 Vpp) Co.
