IR2302S, IR2302 - HALF-BRIDGE DRIVER

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: IR2302S, IR2302. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number IR2302S, IR2302
Manufacturer International Rectifier
File Size 209.25 KB
Description HALF-BRIDGE DRIVER
Datasheet download datasheet IR2302_InternationalRectifier.pdf
Note This datasheet PDF includes multiple part numbers: IR2302S, IR2302.
Please refer to the document for exact specifications by model.

IR2302S Product details

Description

The IR2302(S) are high voltage, high speed power MOSFET and IGBT drivers with dependent high and low side referenced output 8-Lead SOIC IR2302(S) (Also available LEAD-FREE (PbF)) 8-Lead PDIP IR2302 2106/2301//2108//2109/2302/2304 Feature Comparison Part Input logic 2106/2301 21064 2108 21084 2109/2302 21094 2304 HIN/LIN HIN/LIN IN/SD HIN/LIN Crossconduction prevention logic no yes yes yes Dead-Time none Internal 540ns Programmable 0.54~5 µs Internal 540ns Programmable 0.54~5 µs Internal
