IDTQS316211 - QUICKSWITCH PRODUCTS HIGH-SPEED CMOS 24-BIT BUS SWITCH

Integrated Device

📥 Download Datasheet

IDTQS316211 Datasheet Preview — Preview of IDTQS316211 PDF

Datasheet Details

Part number	IDTQS316211
Manufacturer	Integrated Device
File Size	48.87 KB
Description	QUICKSWITCH PRODUCTS HIGH-SPEED CMOS 24-BIT BUS SWITCH
Datasheet	IDTQS316211_IntegratedDeviceTechnology.pdf

IDTQS316211 Product details

Description

APPLICATIONS: Hot-swapping, hot-docking Voltage translation (5V to 3.3V) Logic replacement (data processing) Power conservation Capacitance reduction and isolation Bus isolation Clock gating The QS316211 provides a set of 24 high-speed CMOS TTL-compatible bus switches.The low ON resistance of the QS316211 allows inputs to be connected to outputs without adding propagation delay and without generating additional ground bou

Features

IDTQS316211 Enhanced N channel FET with no inherent diode to Vcc 5Ω bidirectional switches connect inputs to outputs Zero propagation delay, zero ground bounce TTL-compatible input and output levels Undershoot clamp diodes on all switch and control inputs Available in SSOP and TSSOP packages.
