Description
and charts stated herein.
Features
- q q q q q
N channel Logic level Enhancement mode Temperature sensor with thyristor characteristic The drain pin is electrically shorted to the tab
1
2
3
Pin
1 G
2 D
3 S
Type BTS 113A
VDS
60 V
ID
11.5 A
RDS(on)
0.17 Ω
Package TO-220AB
Ordering Code C67078-S5015-A2
Maximum Ratings Parameter Drain-source voltage Drain-gate voltage, RGS = 20 kΩ Gate-source voltage Continuous drain current, TC = 25 °C ISO drain current TC = 85 ˚C, VGS = 10 V, VDS = 0.5 V Pulsed drain current, Short cir.
